DYTRAN 3056系列通用加速度计

发布时间：2021-04-25 17:04:59 浏览：1905

DYTRAN 3056系列是一款经济高效的单轴IEPE加速度计，具有TEDS功能。灵敏度范围从1mV/g到500mv/g

DYTRAN 3056系列设计将陶瓷剪切传感元件整合在坚固的钛壳中，具有10-32轴向连接器和10-32螺柱安装功能。DYTRAN 3056系列是基极隔离，以避免电磁干扰/接地回路干扰，并集成了低噪声JFET电子器件。该装置还密封，以实现在高湿度和肮脏环境中的可靠性能.

特点：

钛

气密

基础隔离

TEDS选项

IEPE

适用范围：

模态分析

振动控制

一般振动监测

深圳市太阳成tyc33455ccwww创展科技有限公司，优势渠道提供DYTRAN传感器产品，欢迎咨询。

详情了解DYTRAN请点击：/brand/52.html

或联系我们的销售工程师：0755-83642657 QQ: 2295048674

MODEL	SPECIFICATIONS
3056B10	10 mV/g sensitivity, 500g range, 10–32 axial connector, 1/4–28 mounting stud, mechanically and electrically filtered, 16 grams, isolated,–67 to +250°F Operation
3056B9	10 mV/g sensitivity, 500g range, 10–32 axial connector, M6 mounting stud, mechanically and electrically isolated, 16 grams, isolated,–67 to +250°F Operation
3056D1	10 mV/g sensitivity, 500g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–67 to +250°F Operation
3056D1T	10 mV/g sensitivity, 500g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–60 to +250°F Operation,–40 to +185°F TEDS Operation
3056D2T	100 mV/g sensitivity, 50g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–67 to +250°F Operation
3056D2T	100 mV/g sensitivity, 50g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–60 to +250°F Operation,–40 to +185°F TEDS Operation
3056D3	500 mV/g sensitivity, 10g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–67 to +225°F Operation
3056D3T	500 mV/g sensitivity, 10g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–60 to +225°F Operation,–40 to +185°F TEDS Operation
3056D4	20 mV/g sensitivity, 250g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–67 to +250°F Operation
3056D4T	20 mV/g sensitivity, 250g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–60 to +250°F Operation,–40 to +185°F TEDS Operation
3056D5	50 mV/g sensitivity, 100g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–67 to +250°F Operation
3056D5T	50 mV/g sensitivity, 100g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–60 to +250°F Operation,–40 to +185°F TEDS Operation
3056D6	200 mV/g sensitivity, 25g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–67 to +225°F Operation
3056D6T	200 mV/g sensitivity, 25g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–60 to +225°F Operation,–40 to +185°F TEDS Operation
3056D7	1 mV/g sensitivity, 5,000g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–67 to +250°F Operation
3056D7T	1 mV/g sensitivity, 5,000g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–60 to +250°F Operation,–40 to +185°F TEDS Operation
3056D8	5 mV/g sensitivity, 1,000g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–67 to +250°F Operation
3056D8T	5 mV/g sensitivity, 1,000g range, 10–32 axial connector, 10–32 tapped hole, 10 grams, isolated,–60 to +250°F Operation,–40 to +185°F TEDS Operation
