HOLT IC航空电子设备MIL-STD-1553 协议IP内核

发布时间：2021-04-14 17:12:48 浏览：1865

Holt MIL-STD-1553/1760 IP解决方案是全世界第一个MIL-STD-1553DALADO-254可认证IP核。它根据HoltHI-6130/31和MAMBATM系列。它在主处理器和MIL-STD-1553B数据总线之间提供了一个完善的单功能或多功能协议接口。提供具备高性能数据同步主机接口的BC、RT或MT功能模块的各种组合。主机接口能够方便地连接到AMBAAXI4接口协议或PCIExpress，启动的终端能够通过共享的双数据总线收发器HI-1587和外部变压器（也可从Holt获得）与MIL-STD-1553数据总线通信。HI-1587具备1.8V、2.5V和3.3V兼容的数字I/O功能模块，包括集成的IP安全模块，这是IP实现所必需的，故此不需要其它IP解决方案中常用的传统外部IP软件芯片。

所有的RT设备均符合MIL-STD-1760标准，并能在通电后150ms内响应状态字忙位的有效信息。

HoltIP Core产品包括HI-6300IPCore，Verilog测试平台和支持文档，使设计者能够在各种FPGA实现中实例化该核。

深圳市太阳成tyc33455ccwww创展科技有限公司，持续提供HOLT IC预定渠道，部分型号备有现货库存，欢迎咨询。

详情了解霍尔IC请点击：http : /public/brand/55.html

或联系我们的销售工程师： 0755-83050846 QQ: 3312069749

HOLT IC.png

Device	Device Type	Description
HI-6300-xxxB	RT/MT IP Core	MIL-STD-1553 / MIL-STD-1760 Remote Terminal / Monitor Terminal IP core. Fully software compatible with HI-6130 and MAMBA hardware families.
HI-6300-xxxC	BC/RT IP Core	MIL-STD-1553 / MIL-STD-1760 Bus Controller / Remote Terminal IP core. Fully software compatible with HI-6130 and MAMBA hardware families.
HI-6300-xxxD	BC/RT/MT IP Core	MIL-STD-1553 / MIL-STD-1760 Bus Controller / Remote Terminal / Monitor Terminal IP core. Fully software compatible with HI-6130 and MAMBA hardware families.
HI-6300-xxxF	RT/MT IP Core DO-254	MIL-STD-1553 / MIL-STD-1760 Remote Terminal / Monitor Terminal IP core. Fully software compatible with HI-6130 and MAMBA hardware families. DO-254 Design Assurance Level A Compliant.
HI-6300-xxxG	BC/RT IP Core DO-254	MIL-STD-1553 / MIL-STD-1760 Bus Controller / Remote Terminal IP core. Fully software compatible with HI-6130 and MAMBA hardware families. DO-254 Design Assurance Level A Compliant.
HI-6300-xxxH	BC/RT/MT IP Core DO-254	MIL-STD-1553 / MIL-STD-1760 Bus Controller / Remote Terminal / Monitor Terminal IP core. Fully software compatible with HI-6130 and MAMBA hardware families. DO-254 Design Assurance Level A Compliant.
